Industrial Power Generation

Centaur 40

< Back

Centaur 40 PG - Generator Set

Centaur® gas turbines are at work today in thousands of installations both offshore and on land ranging from arctic to tropical zones.

ISO Performance/Specifications

Units:
Power 3515 kWe 3515 kWe
Heat Rate 12,240 Btu/kW-hr 12,910 kJ/kW-hr
Exhaust Flow 150,715 lb/hr 68,365 kg/hr
Exhaust Temperature 830ºF 445ºC
Steam Production 19.6 - 112.2 klb/hr 8.9 - 50.9 tonnes/hr
Axial Exhaust Yes Yes
Radial Exhaust — —
SoLoNOx Yes Yes
Ultra Lean Premix — —
  • Introduced in 1969
  • High Efficiency, Simple-Cycle Gas Turbine
  • Designed for Long-Life Industrial Applications
  • Low Dry Emissions (Optional)
  • Designed-In Maintainability
  • Common Engine Skid with Centaur 50 and Taurus 60 Gas Turbines
  • 30-Year Core Engine Service Life
  • 30,000 Hours; Time Between Overhaul (TBO) Interval



Centaur 40 Gas Turbine Generator Set – Power Generation Data Sheet

Learn More

Jesse Brown Veterans Affairs Medical Center

Learn how Solar Turbines helped the US Department of Veteran Affairs reduce utility expenses by providing steam for heat and power using a Centaur 40 cogeneration package.

Learn More
